Description
DISCLAIMER
The NV-450S is primarily used alongside the Netsys NV-450M CO/Master as part of the Netsys Managed G.fast Gigabit Ethernet Extender Kit (NV-450EKIT). Using this product to replace the modem provided by your ISP requires their cooperation, and advanced knowledge of their equipment and configuration settings.
Description
The Netsys NV-450S G.fast/VDSL2/V35b CPE/Slave Modem is an extremely flexible CPE/Slave modem which is compatible with several G.Fast/VDSL2/v35B DPU/DSLAM’s, as well as the NV-450M Managed G.fast CO/Master. (The Netsys NV-450EKIT includes both units for point-to-point Ethernet Extension applications.)
A cost effective solution that delivers high-speed internet access to end-users over existing copper wire infrastructure, the NV-450S supports future-proof super Vectoring (G.fast) compatibility, as well as VDSL2, and VDSL35b, meeting a variety of distance requirements for ISP’s to cover end users.
Please be sure to consult the below compatibility table to ensure the NV-450S is compatible with your DPU/DSLAM before purchasing.
For point-to-point Ethernet Extension applications, please see our NEW Netsys NV-450EKIT Managed G.Fast Gigabit Ethernet Extender (includes NV-450M CO/Master and NV-450S CPE/Slave).
DSLAM Compatibility
Features
- Compliant with ITU-T G.9700/9701 G.fast Standards
- Supports super Vectoring (G.fast), Vectoring (VDSL2), super Vectoring (VDSL35b)
- Supports 212a symmetric/asymmetric and 106a symmetric/asymmetric band profile
- Supports 17a/35b band profile
- Supports dual wave profile 106a/b & 212a/b
- G.fast profile supports up to 1.2Gbps aggregate bandwidth
- Supports Router / bridge mode selection
- Supports IP Multicast, IGMP Proxy, Snooping, Static Routing IPv4, IPv6 forwarding, DHCP
- Server/Relay/Client IPv4/IPv6, DNS Proxy and Relay, NTP Client
- Supports Jumbo frame (MTU) up to 1600 bytes
- Supports MAC Address based filtering
- Supports NTP Time Server
- Supports remote management and monitor
- Supports HTTP/HTTPS web management
- Supports SSH/SSL Security
- Master/Slave Mode selection by firmware upgrading
- Supports Dual Firmware Image Backup
- 4 x RJ-45 10/100/1000Mbps Gigabit Ethernet Ports
- Supports IEEE 802.3 10Base-T, 802.3u 100Base-TX and 802.3ab 1000Base-TX Ethernet Standards
- RJ-11/Terminal block combo for line port
- Surge protection for Line port
- Splitter on board (1 x RJ-11 for POTS/ISDN)
- 2 x USB 3.0 Ports (Future Use)
- Reset Button (Factory Reset)
- Main Chipset : Intel
- CE, FCC, RoHS Compliant
Technical Specifications
Product Kit Contents- 1 X NV-450S Managed G.fast/VDSL2/V35b CPE/Slave Modem
- 1 X AC to DC Power Supply
- 1 X RJ-11 Patch Cable
- 1 X RJ-45 Patch Cable
- 1 X RJ-45 Coupler
- 1 X User Guide Download Link (via email)
- 4 X RJ-45 10/100/1000Mbps auto-negotiation Gigabit Ethernet port
- 1 X RJ-11 / Terminal block combo for VDSL2 line port
- 1 X RJ-11 connector for POTS/ISDN device
- 2 X USB 3.0 for connecting USB Dongle (Future Use)
- 1 X Reset Button for resetting to factory default
- 1 X Power LED
- 4 X Link/Active Status for Ethernet port
- 1 X G.fast Link LED
- 1 X xDSL Link LED
- 1 X Master LED
- Store and forward
- Full duplex: IEEE 802.3x
- Half duplex: Back pressure
- 8.16W (full load without USB device), 18.16W (full load with 2 x USB devices)
- External switching power adapter (Input: AC 85~240 Volts/50~60Hz, Output: DC 12V/2A)
- 0°C ~ 50°C (32°F ~ 122°F) Fanless, free air cooling)
- -20°C ~70°C (-4°F ~ 158°F)
- 10 to 90% (non-condensing)
- 196 x 146 x 40 mm (7.7" x 5.74 " x 1.57")
- 2 lbs (0.9 kg)
- FCC 47 CFR Part 15 Subpart B Class A, CE, ROHS
- 2 years (parts only)
